WATTAGE PER METER
4W-5W
LUMINOUS FLUX PER METER
260 – 500 LM
LIGHT EFFICACY
65 - 100 LM/W
CRI
70, 80, 90
RADIANCE ANGLE
120°
CUT-ABLE POINTS
3 LEDS FOR 12V, 6 LEDS FOR 24V
IP LEVEL
IP20, IP65
AVAILABLE PCBs
SINGLE SIDE PCB
DOUBLE SIDE PCB
AVAILABLE VOLTAGE
STRIP STRUCTURE
INSTALLATION GUIDE
Dry the position to be flat and smooth before putting on the strip
LED tape can be cut only between soldering pads
Solder wires on soldering pads (label +/-). The solder temperature may not exceed 350 for maximum duration of 2 seconds.
You can also connect strips using LED tape connectors.connectors.
LED tapes are bendable. Minimum bend radius is 30 mm
LED tapes must be installed on aluminum (or material with similar thermal conduction) to avoid LEDs overheating and ensure proper heat dissipation. Measure TC temperature after 30 minutes of operation. TC temperature should not exceed 75.
RELATED PRODUCTS
APPLICATIONS
Signages
Our LED strip lights are a versatile and effective way to create eye-catching signage. They can be used to create logos, directional arrows, and other informative or promotional messages.
Know More
Occaisons
Our LED strip lights can add a touch of festive cheer to any occasion. They can be used to create festive lighting displays for holidays, weddings, and other special events.
Know More
Backlit Panels
Our LED strip lights can be used to create elegant and modern backlit panels. They can be used to highlight artwork, product displays, and other features.
Know More
Underwater IP68
Our LED strip lights are ideal for underwater applications. They are durable, waterproof, and can withstand harsh marine environments.
Know More
Our LED strip lights are a versatile and effective way to create eye-catching signage. They can be used to create logos, directional arrows, and other informative or promotional messages.
Our LED strip lights can add a touch of festive cheer to any occasion. They can be used to create festive lighting displays for holidays, weddings, and other special events.
Our LED strip lights can be used to create elegant and modern backlit panels. They can be used to highlight artwork, product displays, and other features.
Our LED strip lights are ideal for underwater applications. They are durable, waterproof, and can withstand harsh marine environments.
