LED TYPE : 5050 RGBWW
Voltage
24VDC
Watts/M
10.52W
AVAILABLE LED COLOURS
RGBW
Width
12mm & 14mm 3oZ
Length
5m
Voltage
12/24 VDC
Watts/M
10.52W
CUT-ABLE POINTS
6 LEDs for 24V
Red
635 nm; 51.97lm
Green
515 nm; 128.59lm/M
Blue
465 nm; 30Lm/M
Warm White
2400K; 176.07Lm/M
Cold White
6500K; 218.45Lm/M
Mixed Colors
6500K; 583.46Lm/M
STRIP STRUCTURE
INSTALLATION GUIDE
Dry the position to be flat and smooth before putting on the strip
LED tape can be cut only between soldering pads
Solder wires on soldering pads (label +/-). The solder temperature may not exceed 350 for maximum duration of 2 seconds.
You can also connect strips using LED tape connectors.connectors.
LED tapes are bendable. Minimum bend radius is 30 mm
LED tapes must be installed on aluminum (or material with similar thermal conduction) to avoid LEDs overheating and ensure proper heat dissipation. Measure TC temperature after 30 minutes of operation. TC temperature should not exceed 75.
